What Are 13 Inch 4x100 Wheels & Which Cars Use Them?

If you're searching for 13 inch wheels with a 4x100 bolt pattern, you're likely replacing factory rims on a compact car, microcar, or small European import. These dimensions are most commonly found on older Honda models, certain Kia and Hyundai vehicles, and light-duty city cars like the Aixam, Ligier, or Microcar Dué. Understanding the exact specifications—such as pitch circle diameter (PCD), center bore, offset (ET), and load rating—is critical to ensure safe, vibration-free operation and proper fitment without rubbing or clearance issues.

Understanding Wheel Specifications: What Does 13x4x100 Mean?

The term 13 inch 4x100 wheels refers to two primary measurements: wheel diameter and bolt pattern. The "13 inch" indicates the diameter of the wheel from one bead seat to the opposite side, measured in inches. This size is typically used on smaller passenger vehicles where low unsprung weight, fuel efficiency, and tight turning radius matter.

The "4x100" portion describes the bolt pattern (also known as PCD – Pitch Circle Diameter). It means the wheel has four lug holes spaced evenly around an imaginary 100mm-diameter circle. This configuration is common among Japanese and some European manufacturers but less so in American or larger SUV platforms.

To verify if a wheel fits your vehicle, all three specs must match:

• Diameter: 13 inches
• Bolt Count & Spacing: 4 bolts, 100mm apart on center
• Center Bore: Must match or be adaptable to your hub size

Common Vehicles That Use 13" 4x100 Wheels

While not universal across all trims or model years, several popular makes and models originally came equipped with 13 inch 4x100 rims. Knowing whether your car uses this setup helps avoid costly mistakes when shopping for replacements.

Vehicle Make/Model	Years Produced	Notes
Honda Civic (base models)	1996–2000	DX and LX trims often had 13-inch steel wheels
Honda Fit (first generation)	2007–2013	Some international markets shipped with 13" alloys
Kia Picanto / Hyundai Atos	2000–2011	Frequent use of 4x100 PCD and 13" diameter
Aixam City / Crossline	2005–present	European microcars using lightweight 13" setups
Ligier JS50 / Xeo	2008–present	Requires specific offset and hub-centric design
Microcar Virgo / MC series	2000s–2010s	Often paired with narrow tires (155/65R13)

🔧 Pro Tip: Always double-check your current wheel’s stamping. Most OEM wheels have the PCD, offset, and center bore stamped near the hub or behind the spokes. Look for markings like "4x100", "ET30", or "57.1".

Offset (ET) and Hub Bore: Why They Matter Just As Much

Selecting a wheel based only on diameter and bolt pattern can lead to serious issues. Two other critical factors are offset (ET) and hub bore diameter.

Offset determines how far the mounting surface sits relative to the centerline of the wheel. For example, an ET30 rim means the hub mounts 30mm toward the outer edge of the wheel. Too high an offset pushes the tire inward, risking suspension contact. Too low (negative ET) causes the wheel to stick out, increasing stress on bearings and potentially violating local regulations.

📍 Typical Offset Range: Most 13x4x100 wheels fall between ET25 and ET40. Microcars like the Aixam may require ET35–ET45 for proper fender alignment.

The hub bore is the hole in the center that fits over the axle hub. Factory wheels are usually hub-centric, meaning they center on the hub before lug bolts secure them. Aftermarket wheels may be lug-centric, relying on lug torque to center the wheel—which can cause imbalance if not perfectly aligned.

⚙️ If the aftermarket wheel has a larger hub bore than your axle (e.g., 60mm vs. 57.1mm), you’ll need hub-centric rings to prevent wobbling at speed.

Steel vs. Alloy: Choosing the Right Material for 13" 4x100 Rims

When replacing or upgrading 13 inch 4x100 wheels, you’ll encounter both steel and alloy options. Each has pros and cons depending on your priorities: durability, weight, aesthetics, or cost.

Steel Wheels (OEM Style)

🛒 Commonly found on base trim levels, steel rims are durable, inexpensive, and easy to repair after pothole damage. They’re heavier than alloys, which slightly reduces fuel economy and handling responsiveness.

• Pros: Affordable, strong, compatible with full-size spare kits
• Cons: Heavier, prone to rust if finish is damaged, limited styling options

Alloy Wheels (Aftermarket Upgrade)

✨ Lightweight aluminum alloys improve acceleration, braking, and ride comfort due to reduced rotational mass. Many modern designs offer sporty finishes like gunmetal, matte black, or machined faces.

• Pros: Lighter, better heat dissipation, improved appearance
• Cons: More expensive, brittle under impact (can crack), harder to refinish

📌 Note: Some 13-inch alloy wheels marketed online (especially from global suppliers) may lack proper certifications like JWL or VIA. Check product details for compliance standards if safety and road legality are concerns.

Where to Buy 13 Inch 4x100 Wheels: Online Marketplaces & Specialty Shops

Purchasing replacement wheels requires balancing availability, price, shipping costs, and return policies. Several types of retailers serve this niche market:

General E-commerce Platforms

Sites like eBay or Alibaba list numerous 13 inch 4x100 wheels, especially from Chinese manufacturers. While prices can be attractive, buyers should watch for:

• Inaccurate PCD labeling (some sellers confuse 4x100 with 4x114.3)
• Vague descriptions lacking ET or center bore data
• Long shipping times and unclear warranty terms

🌐 Tip: Use filters carefully. Search phrases like "13 inch 4x100 ET30" yield more accurate results than generic "13 inch rims 4 lug."

European Specialty Retailers

For microcars like Ligier or Aixam, dedicated EU-based shops such as TrailerPlus.eu or Pro VSP stock correct-spec 13" 4x100 steel rims. These often include proper load ratings (e.g., 650kg per wheel) and hub-centric fitment.

🚚 Advantage: Faster delivery within Europe, technical support, and verified compatibility.

Custom Wheel Fabricators

Some companies offer made-to-order 13" wheels tailored to non-standard offsets or widths. This is useful for modified builds or rare imports where off-the-shelf options don’t exist.

⏱️ Drawback: Longer lead times and higher pricing compared to stock items.

Tire Sizing for 13 Inch 4x100 Wheels: Matching Width and Profile

Your choice of wheel width affects which tires will safely fit. Standard widths for 13" 4x100 wheels range from 4.5J to 6J.

Wheel Width	Recommended Tire Size	Common Applications
4.5J	155/65R13 or 165/60R13	Microcars, basic sedans
5J	165/65R13 or 175/60R13	Honda Fit, older Civics
5.5J–6J	175/65R13 or 185/60R13	Performance trims, upgraded models

🧼 Important: Never mount a tire wider than recommended for the rim. Overly wide tires can rub fenders or suspension components, especially during turns or bumps.

Common Misconceptions About 13" 4x100 Wheels

Despite being a standardized measurement, confusion persists around compatibility and performance. Let’s clarify some frequent misunderstandings.

Misconception #1: All 4-Lug 13-Inch Wheels Are Interchangeable

❌ False. A 4x100 bolt pattern is not the same as 4x114.3 (used by many Toyotas) or 4x108 (Ford and some Volvos). Even with the same number of lugs, mismatched PCD prevents installation. Adapters exist but introduce risks if poorly designed.

Misconception #2: Smaller Wheels Automatically Improve Fuel Economy

⚡ Partially true—but only if combined with appropriate gearing and tire profile. Simply switching to 13" wheels without adjusting overall rolling diameter can skew speedometer readings and reduce highway efficiency.

Misconception #3: You Can't Upgrade Styling on Small Wheels

✅ Debunked. Modern 13-inch alloy designs feature deep concave profiles, multi-spoke patterns, and custom finishes. Brands like Mad In and Kipardo offer stylish yet functional 13x4x100 options for niche applications.

Installation Tips and Safety Checks

Once you’ve selected the right 13 inch 4x100 wheel, proper installation ensures long-term reliability.

• Use a torque wrench: Lug nuts should be tightened to manufacturer specification (typically 80–90 Nm for small cars).
• Re-torque after 50–100 miles: This confirms no settling or loosening occurred after initial drive.
• Check for clearance: Turn steering lock-to-lock and bounce suspension to detect rubbing.
• Balance tires: Even slight imbalance is noticeable at speed on lightweight wheels.

❗ Warning: Avoid using locking lug nuts unless necessary. They complicate roadside flat changes and may fail if low-quality.

When Not to Use 13 Inch 4x100 Wheels

Not every situation calls for this size. Consider these red flags before purchasing:

• Upgrading from larger wheels: Dropping below 14" may affect stability, especially at highway speeds.
• Heavy cargo or towing: Verify load capacity per wheel (often listed as kg or lbs on the rim).
• Retrofitting onto incompatible vehicles: Forced fitment via spacers or adapters compromises safety.
• Extreme climates: Thin steel rims corrode faster in salty winter roads; alloys crack under repeated freeze-thaw cycles.

Summary: Key Points Before Buying 13" 4x100 Wheels

Before finalizing your purchase, confirm the following:

1. ✅ Bolt Pattern: Exactly 4x100 mm
2. ✅ Diameter: 13 inches (measured at bead seat)
3. ✅ Offset (ET): Matches original spec (commonly ET25 to ET40)
4. ✅ Center Bore: Equal to or larger than your hub (with adapter ring if needed)
5. ✅ Load Rating: Suitable for vehicle weight (check VIN plate or manual)
6. ✅ Certification: Look for JWL, TÜV, or ISO marks on alloys

📋 Final Advice: Take photos of your current wheels, note all visible specs, and consult a professional installer if unsure. Investing time upfront prevents unsafe driving conditions later.

Frequently Asked Questions (FAQ)

Can I use 4x100 wheels on a 4x114.3 hub?

No, the bolt patterns are incompatible. Using adapters introduces stress points and potential failure. Always match PCD exactly or choose a different wheel.

Are 13 inch 4x100 wheels still being manufactured?

Yes, though primarily for replacement or specialty vehicles like microcars. New production continues through suppliers in Europe and Asia for OEM and aftermarket channels.

What does 'ET30' mean on a 13 inch rim?

ET30 refers to the offset: the mounting surface is 30mm from the wheel's centerline toward the outside. This affects how far the wheel protrudes from the fender.

Do I need hub-centric rings for my 13x4x100 wheels?

If the wheel’s center bore is larger than your vehicle’s hub (e.g., 60mm vs. 57.1mm), yes. Rings ensure precise centering and reduce vibration risk.

Can I put bigger tires on my 13 inch 4x100 wheels?

Only within safe limits. Increasing width beyond +10mm or altering aspect ratio significantly affects speedometer accuracy, clearance, and handling. Consult a tire guide before upsizing.
